Supported processors :

Compatible with 8th and 9th Gen Intel® Core™ i9, Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, Intel® Pentium®, Intel® Celeron® processors (Socket LGA1151)

Chipset :

Intel® Z390 Express

Memory subsystem:

4 × DIMM DDR4 maximum memory 128 GB (32 GB for a single DIMM); Dual-channel memory mode; Compatible with RAM modules 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400 (O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz; Support for 1Rx8/2Rx8 RAM DIMMs without ECC and buffering (operate in non-ECC mode); Support for non-ECC DIMMs without buffering 1Rx8/2Rx8/1Rx16; Support for XMP memory profiles (Extreme Memory Profile

Interfaces for expansion boards:

PCI Express 3.0x16 - 1 slot, PCI Express 3.0x4 - 2 slots, PCI Express 3.0x1 - 3 slots

Video subsystem scalability:

AMD Quad-GPU CrossFire™, 2-Way AMD CrossFire™

Drive interfaces:

1 x M.2 (Socket 3, Key M, Type 2242/2260/2280/22110 SATA and support PCIe x2/x4 SSD); 6 x SATA 6Gb/s; Support for RAID 0, RAID 1, RAID 5 and RAID 10

Network interface :

Intel® GbE LAN Network Controller RTL8118AS (10/100/1000 Mbps)

Audio subsystem:

2/4/5.1/7.1 - channel HDА codec (Realtek® ALC887 audio codec). Digital S/PDIF output

Interfaces and buttons on the rear panel:

1 PS/2 keyboard and mouse, 1 DVI-D, 1 DisplayPort, 1 HDMI, 1 USB Type-C™ for USB 3.1 Gen 1, 1 USB 3.1 Gen 2 Type-A, red connector), 2 USB 3.1 Gen 1 ports, 2 USB 2.0/1.1 ports, 1 RJ-45 LAN socket, 6 audio jacks.

Interfaces and buttons on the motherboard:

One 24-pin ATX power connector, 8-pin ATX 12V power connector, 2x M.2 Socket 3, 6x SATA, up to 6Gb/s bandwidth, CPU fan header, 3x system fan headers, 1 connector for connecting RGB LED-bars, 1 connector on the front panel, Header for audio connectors on the front panel, 1 connector for USB 3.1 Gen 1 ports, 2 connectors for connecting USB 2.0/1.1 ports, 1 <Output> S/PDIF connector, 1x Thunderbolt™ Expansion Card Connector, TPM (Trusted Platform Module) Connector, 2x6 pins for GC-TPM2.0_S module only, Optional TPM function (depending on product shipments to specific regions), 1 COM port, Jumper for return CMOS settings to <Default>

BIOS :

Dual 128Mbit ROM, Licensed AMI UEFI BIOS, DualBIOS™ support, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Peculiarities :

Support for proprietary APP Center utility. The availability of certain utilities in the APP Center application depends on the model of the motherboard. The functionality of a particular utility may differ depending on the model of the motherboard. 3D OSD Function, @BIOS™ Proprietary Utility, Ambient LED Function, Auto Green Proprietary Function, Cloud Station Support, EasyTune Utility, Easy RAID Function, Fast Boot Function, Game Boost Function, GIGABYTE Proprietary On/Off Charge Technology, Platform Power Management, Smart Backup, Smart Keyboard, Smart TimeLock, Smart HUD, Smart Survey, System Summary, USB Blocker Proprietary, V-Tuner Proprietary, Q-Flash Proprietary, Xpress Support

Form factor :

MicroATX; 244 x 244 mm

Contents of delivery :

Motherboard, User manual (English only), DVD with software and drivers, 2 SATA cables, Back panel blank

Guarantee period :

12 months
